Technology Highlight
1.Large capacity cavity of vacuum pump —— The displacement of improved vacuum pump is two times bigger than the former one, the priming time is shorter, the water comes out faster, the suction head is higher, could reach 9 meters.
2.Maintenance-free battery —— Electric starting is equipped with maintenance-free battery. It can prevent electrolyte from leakage to pollute the environment. The stable and reliable battery can ensure that the machine starts normally at any time.
3.Muti-equipment connection —— Dedicated connection tool makes multi-equipment work at the same time to achieve distant water supply.
4.Auto-charging device——The machine with auto-charging device can charge the battery when operating in order to ensure adequate battery.
5.Low noise ——Well-designed muffle with large capacity can absorb engine’s noise to reduce the noise pollution efficiently.
6.Two outlets —— Two outlets with 90° rotating guarantee water supply and ensure the water consumption at any time.
7.Automatic stop protection device —— The equipment is equipped with Engine oil protective device, which can prevent engine to continue to operate without oil.
Technology Parameter
| Engine | Type | 4-stroke | water pump | Pump | Single suction single-stage impeller |
| Cylinders | V-Twin | Suction Diameter | 3”（80mm） | ||
| Bore*Stroke（mm） | 78×72（688cc） | Suction Thread | JIS Screw type | ||
| Max. Output | 27PS（20Kw） | Outlet Dia | 2.5”（65mm） | ||
| Authorized Output | 20PS（14.8Kw） | Outlet Thread | Srew type | ||
| Fuel Type | No.92 or above Gasoline | Outlet Quantity | 2 | ||
| Fuel Tank | 15L | ||||
| Fuel System | Solenoid Valve-Carburetor | Outlet Valve Type | Ball Valve | ||
| Lubrication | Forced lubrication system | Priming Type | Vacuum Pump | ||
| Oil Capacity | 1.8L | Priming Time | ≤15S | ||
| Start Way | Electric or manul（Remote start is available） | Max. Suction depth | 9m | ||
| Method Of Ignition | D.C.I | Outlet Performance | 660 L/min.at1.0Mp | ||
| Consumption | 7L/h | 1000 L/min.at 0.8Mpa | |||
| 1200 L/min.at 0.6 Mpa | |||||
| Pump Lift | 145m | ||||
| Size | L×W×H（mm） | 780×600×650 | Dry Weight | Net Weight | 98kg |
